S111Root
- class s100py.s111.v1_2.api.S111Root(recursively_create_children=False, **kywrds)
Bases:
S100RootThe root group contains a feature information group and N feature containers. In S111 there is one feature container ‘surface current’. The coverage names are determined from the matching CoveragesAttributes 10.2.1, 10.2.2 and Table 12.1 of v1.0.1
Attributes Summary
Eastern extent
Northern extent
Southern extent
Western extent
Methods Summary
add_data(key, value)Creates a blank, empty or zero value for dataset_delivery_interval
Creates a value using the first item in the enumeration of depth_type_index
Creates a blank, empty or zero value for epoch
Creates a blank, empty or zero value for false_easting
Creates a blank, empty or zero value for false_northing
Creates a blank, empty or zero value for geographic_identifier
Gets all the non-standard keys that are contained in this object currently as well as all the standard keys (S100/HDF5 style names) that could be added.
Override this method if the dtype of compound dataset items is important
get_data(key)get_hdf5_from_file(file_obj)get_s1xx_attr(s1xx_name)Returns the S100 (HDF5) names for the things that are listed in the specs for this class.
Returns a list of properties that are lists (children based on S1xxCollection).
This function autodetermines the properties implemented (which have get/set @properties and _hdf_name associated)
This function autodetermines the HDF5 or xml names and their associated property names.
Override this method if the data types of attributes/groups/dataset items is important
Override this method if the write order of attributes/groups/dataset items is important
Creates a blank, empty or zero value for horizontal_crs
Creates a blank, empty or zero value for horizontal_cs
Creates a blank, empty or zero value for horizontal_datum
initialize_properties([...])Calls the create function for all the properties of the class.
Creates a blank, empty or zero value for issue_date
Creates a blank, empty or zero value for issue_time
Creates a blank, empty or zero value for meta_features
Creates a blank, empty or zero value for metadata
Creates a blank, empty or zero value for name_of_horizontal_crs
Creates a blank, empty or zero value for name_of_horizontal_datum
Creates a blank, empty or zero value for prime_meridian
Creates a blank, empty or zero value for product_specification
Creates a blank, empty or zero value for projection_method
Creates a blank, empty or zero value for projection_parameter_1
Creates a blank, empty or zero value for projection_parameter_2
Creates a blank, empty or zero value for projection_parameter_3
Creates a blank, empty or zero value for projection_parameter_4
Creates a blank, empty or zero value for projection_parameter_5
read(group_object)Given an h5py.File or a h5py group then read the data based on the encoded S100+ spec.
read_simple_attributes(group_object)Reads the standard simple types (strings, ints, floats, datetimes, enums) from the given group as specified by the class specs.
set_datetime_attribute(val, hdf_name, date_type)set_enum_attribute(val, hdf_name, enum_type)Function to set an attribute that is an enumeration type using either it's string or numeric value or enumeration instance.
set_s1xx_attr(s1xx_name, val)Creates a blank, empty or zero value for spheriod
Creates a blank, empty or zero value for surface_current_depth
Creates a blank, empty or zero value for type_of_horizontal_crs
Creates a blank, empty or zero value for vertical_coordinate_base
Creates a blank, empty or zero value for vertical_cs
Creates a blank, empty or zero value for vertical_datum
Creates a blank, empty or zero value for vertical_datum_reference
write(group_object)write the contained data and all it's children into an HDF5 file using h5py.
write_as_xml(etree_object)write_simple_attributes(group_object)Attributes Documentation
- dataset_delivery_interval
- depth_type_index
- east_bound_longitude
Eastern extent
- epoch
- false_easting
- false_northing
- feature_information
- geographic_identifier
- horizontal_crs
- horizontal_cs
- horizontal_datum
- issue_date
- issue_time
- meta_features
- metadata
- name_of_horizontal_crs
- name_of_horizontal_datum
- north_bound_latitude
Northern extent
- prime_meridian
- product_specification
- projection_method
- projection_parameter_1
- projection_parameter_2
- projection_parameter_3
- projection_parameter_4
- projection_parameter_5
- south_bound_latitude
Southern extent
- spheriod
- surface_current
- surface_current_depth
- type_of_horizontal_crs
- vertical_coordinate_base
- vertical_cs
- vertical_datum
- vertical_datum_reference
- west_bound_longitude
Western extent
Methods Documentation
- add_data(key, value)
- dataset_delivery_interval_create()
Creates a blank, empty or zero value for dataset_delivery_interval
- depth_type_index_create()
Creates a value using the first item in the enumeration of depth_type_index
- east_bound_longitude_create()
- epoch_create()
Creates a blank, empty or zero value for epoch
- false_easting_create()
Creates a blank, empty or zero value for false_easting
- false_northing_create()
Creates a blank, empty or zero value for false_northing
- feature_information_create()
- geographic_identifier_create()
Creates a blank, empty or zero value for geographic_identifier
- get_all_keys()
Gets all the non-standard keys that are contained in this object currently as well as all the standard keys (S100/HDF5 style names) that could be added.
- Return type:
list
- get_compound_dtype()
Override this method if the dtype of compound dataset items is important
- Return type:
A list of dtype, None otherwise.
- get_data(key)
- get_hdf5_from_file(file_obj)
- get_s1xx_attr(s1xx_name)
- get_standard_keys()
Returns the S100 (HDF5) names for the things that are listed in the specs for this class.
- Returns:
The S102 HDF5 group/attribute/dataset names from this object that will be written or read from an HDF5 file. e.g. BathymetryCoverage or westBoundLongitude etc.
For the class “Root”: [‘BathymetryCoverage’, ‘Group_F’, ‘TrackingListCoverage’]
- Return type:
list
- get_standard_list_properties()
Returns a list of properties that are lists (children based on S1xxCollection). Basically a way of finding which items will be named <name>_001, <name>_002 etc
- Returns:
The property names that will have auto-generated names based on their index in a list.
- Return type:
list
- classmethod get_standard_properties()
This function autodetermines the properties implemented (which have get/set @properties and _hdf_name associated)
- Returns:
Names of the properties implemented.
For eample class “Root” might have (for S102): [‘bathymetry_coverage’, ‘feature_information’, ‘tracking_list_coverage’]
- Return type:
list
- get_standard_properties_mapping()
This function autodetermines the HDF5 or xml names and their associated property names. Keys are the s100 (HDF5 spelling) strings and the values are the python style naming.
- Returns:
dictionary of xml element names as keys and property names as values.
For the class “Root”: {‘BathymetryCoverage’: ‘bathymetry_coverage’, ‘Group_F’: ‘feature_information’, ‘TrackingListCoverage’: ‘tracking_list_coverage’}
- Return type:
dict
- get_write_dtypes()
Override this method if the data types of attributes/groups/dataset items is important
- Return type:
A list of tuples having key names and type, None otherwise.
- get_write_order()
Override this method if the write order of attributes/groups/dataset items is important
- Return type:
A list of key names if order is important, None otherwise.
- horizontal_crs_create()
Creates a blank, empty or zero value for horizontal_crs
- horizontal_cs_create()
Creates a blank, empty or zero value for horizontal_cs
- horizontal_datum_create()
Creates a blank, empty or zero value for horizontal_datum
- initialize_properties(recursively_create_children=False, overwrite=True)
Calls the create function for all the properties of the class. Default values will be created for each attribute that is expected to be contained in this object.
For example, say a class has simple attributes of ESPG code (int) and locatilty (str) and then a class made from S1xxObject called “extents” which has east and west inside it.
Calling initialize_properties(recursively_create_children=False) would result in EPSG=0, locality=”” and an instance of the “extents” class but NO value (nothing would be written to HDF5) for east, west.
Calling initialize_properties(recursively_create_children=True) would result in EPSG=0, locality=”” and an instance of the “extents” class but with east=0.0 and wesst=0.0 as well.
Calling initialize_properties(recursively_create_children=True, overwrite=False) with an esiting dataset, say locality=”test” would result in EPSG=0 being made, locality=”test” being retained and an instance of the “extents” class with east=0.0 and wesst=0.0 as well.
- Parameters:
recursively_create_children – True = Create children for any child data that would have other children False = Only create data for immediate children of this instance
overwrite – True = Overwrite existing data with new default data False = Keep existing data if it exists but create new data otherwise
- Return type:
None
- issue_date_create()
Creates a blank, empty or zero value for issue_date
- issue_time_create()
Creates a blank, empty or zero value for issue_time
- meta_features_create()
Creates a blank, empty or zero value for meta_features
- metadata_create()
Creates a blank, empty or zero value for metadata
- name_of_horizontal_crs_create()
Creates a blank, empty or zero value for name_of_horizontal_crs
- name_of_horizontal_datum_create()
Creates a blank, empty or zero value for name_of_horizontal_datum
- north_bound_latitude_create()
- prime_meridian_create()
Creates a blank, empty or zero value for prime_meridian
- product_specification_create()
Creates a blank, empty or zero value for product_specification
- projection_method_create()
Creates a blank, empty or zero value for projection_method
- projection_parameter_1_create()
Creates a blank, empty or zero value for projection_parameter_1
- projection_parameter_2_create()
Creates a blank, empty or zero value for projection_parameter_2
- projection_parameter_3_create()
Creates a blank, empty or zero value for projection_parameter_3
- projection_parameter_4_create()
Creates a blank, empty or zero value for projection_parameter_4
- projection_parameter_5_create()
Creates a blank, empty or zero value for projection_parameter_5
- read(group_object)
Given an h5py.File or a h5py group then read the data based on the encoded S100+ spec.
- Parameters:
group_object – The group (an h5py.File is a group too) to read from.
- Return type:
None
- read_simple_attributes(group_object)
Reads the standard simple types (strings, ints, floats, datetimes, enums) from the given group as specified by the class specs.
- Parameters:
group_object – The group (an h5py.File is a group too) to read from.
- Return type:
None
- set_datetime_attribute(val, hdf_name, date_type)
- set_enum_attribute(val, hdf_name, enum_type)
Function to set an attribute that is an enumeration type using either it’s string or numeric value or enumeration instance.
- Parameters:
val – The value as a string, int or Enum().
hdf_name – The S100 name (hdf5 spelling).
enum_type – The class of enumeration to use if an instance needs to be created.
- Return type:
None
- set_s1xx_attr(s1xx_name, val)
- south_bound_latitude_create()
- spheriod_create()
Creates a blank, empty or zero value for spheriod
- surface_current_create()
- surface_current_depth_create()
Creates a blank, empty or zero value for surface_current_depth
- type_of_horizontal_crs_create()
Creates a blank, empty or zero value for type_of_horizontal_crs
- vertical_coordinate_base_create()
Creates a blank, empty or zero value for vertical_coordinate_base
- vertical_cs_create()
Creates a blank, empty or zero value for vertical_cs
- vertical_datum_create()
Creates a blank, empty or zero value for vertical_datum
- vertical_datum_reference_create()
Creates a blank, empty or zero value for vertical_datum_reference
- west_bound_longitude_create()
- write(group_object)
write the contained data and all it’s children into an HDF5 file using h5py.
- Parameters:
group_object – An h5py.File or an h5py group object
- Return type:
None
- write_as_xml(etree_object)
- write_simple_attributes(group_object)
- __init__(recursively_create_children=False, **kywrds)
